AISWare HyperView realizes 3D Data Center Visualization

Customer requirement

With the development of IT infrastructure applications in depth, large or ultra-large data center are constantly emerging. Its related applications are showing "data centralization, system heterogeneity, and application diversification. " Customers are facing the problems like how to reduce the operating cost of the data center, how to improve the capability of information management and how to improve the energy and operation efficiency. Customers urgent need a clear-structure, intuitive-operation, and convenient-management 3D date center management platform. The management and operation of data center will be based on 3D visualization. The effective management and working status of the data center are combined on the same platform, thereby improving the operation management experience and efficiency of the data center.

Construction plan

3D modeling visualization technology and Internet of Things technology are used to construct a 3D-model data center. It will connect the equipment and systems in real-time, and show the 3D model, real-time data and alarms by screen, and realize the data center sandbox and digital twin. So it improves the management level of the data center, enriches display ways, and speeds up the response speed. The main functions are as follows: 3D modeling the data center buildings and equipment lights; Connecting equipment and sensors, collect data, display the model and data through screen, and display it by 3D visualization, construct a 3D data center sandbox, and realize digital twins; Implement the comprehensive perception of data center and improve the monitoring, evaluation and control capabilities of the date center; Deep search the topology and application system of devices, in order to get the fine-grained analysis of the energy consumption in data center;

Application effect

  • Fancy Model, Stereo display

    3D image visualization is a solution to the problem that flooding of data and reports due to insufficient 2D information display. It effectively improves the level of monitoring and management.

  • Automatic monitoring, Unified management, Test 24/7

    Automated monitoring and management, unified access to multiple systems and devices, reducing maintenance personnel;24/7 inspection, there are 7 alarm ways to do real-time alarms when abnormal things are found, and comprehensive environmental security.

  • Security risks, Real-time warning

    Monitor the warning information from equipments in real time, locate the alarm equipment quickly, and reduce the time of overhauling equipment.

  • Comprehensive analysis, Accurate evaluation

    Multi-dimensional data query and report analysis provide reliable basis for maintenance, planing and upgrading of equipments in buildings.
